Description
Standard Accessories:
1.Table splash guard.
2.Pre-extensioned ballscrew.
3.Auto lubrication.
4.Working lamp & alarm light.
5.Heat exchanger on elec. cabinet.
6.Levelling pads & bolts.
7.Adjusting tools & box.
Optional Accessories :
1.Full splash guard.
2.Coolant thru spindle.
3.Coolant thru tool holder.
4.Auto tool length measurement.
5.Workpiece probe.(Renishaw MP-10/12)
6.BT#40 spindle & 10000 RPM.
7.M30 auto power off function.
| SPECIFCATIONS | Model | MC-1600P |
|---|---|---|
| TABLE OVERALL SIZE | MM | 1700 X 815 |
| WORKING AREA | MM | 1700 X 815 |
| T-SLOTS(WIDTH/NO/PITCH) | MM | 18 X 5 X 150 |
| TABLE MAX. LOADING | KG | 2000 |
| X / Y / Z TRAVEL | MM | 1600 / 815 / 700 |
| SPINDLE TO COLUMN WAYS | MM | 855 |
| SPINDLE TO TABLE TOP | MM | 200-900 |
| FLOOR TO TABLE SURFACE | MM | 850 |
| SPINDLE TAPER | BT# | 50(40) |
| SPINDLE SPEED | RPM | 4000(6000) |
| FRONT BEARING DIAMETER | MM | 90 |
| SPINDLE MOTOR | KW | 11/15 |
| X / Y / Z SERVO MOTOR | KW | 3.7 |
| X / Y / Z CUTTING FEEDRATE | MM/MIN | 1-8000 |
| X / Y / Z RAPID TRAVERSE | MM/MIN | 10/10/10 |
| TYPE OF ATC | ARM | ARM |
| NO. OF ATC TOOLS | PCS | 20(32.40) |
| MAX. TOOL (DIA / LENGTH) | MM | 125/400 |
| MAX. TOOL WEIGHT | KG | 15 |
| TOOL TO TOOL | SEC. | 3.5 |
| CHIP TO CHIP | SEC. | 10 |
| DIA. X PITCH (X.Y.Z. AXIS) | MM | 50 X 10 |
| PRECISION CLASS | MM/300MM | C3 0.008 |
| MACHINE WEIGHT | KG | 15000 |
| POWER REQUIREMENT | KVA | 30 |
| PNEUMATIC REQUIRED | KG/CM | 7 |
